Vehicle model （M1）
|
LOJO-E300 super
|
|
specification
|
|
L×W×H（mm）
|
3370X1500X1550
|
|
Wheel base (mm）
|
2210
|
|
Track width Front（mm）
|
1290
|
|
Track width Rear（mm）
|
1290
|
|
Curb weight（kg）
|
570(without Battery）/850(with Battery）
|
|
Payload （kg）
|
280kg
|
|
Passenger
|
4
|
|
Performance
|
|
Max Speed（km/h）
|
120
|
|
Acceleration time（ S 0-80km）
|
10
|
|
Maximum grade ability
|
20%
|
|
Min turning diameter（m）
|
<8
|
|
Departure angle（°）
|
≥38
|
|
Approach angle（°）
|
≥35
|
|
Ground clearance（mm)
|
≥170
|
|
Body Structure
|
|
Body of Cabin
|
sheet metal
|
|
Cargo box
|
sheet metal
|
|
Battery/Motor
|
|
Battery capacity (V/Ah）
|
120V ,250Ah
|
|
Max. Range(km)
|
>300
|
|
Battery Type
|
lihium battery
|
|
Charger
|
Portable/car charger
|
|
Charging time(h)
|
8~10
|
|
Motor type
|
AC asynchronous motor
|
|
Rated Power（KW）
|
20KW
|
|
Chassis/Brake
|
|
Drive type
|
RWD
|
|
Front Suspension
|
double wishbone coil spring independent suspension
|
|
Rear suspension
|
non - independent suspension
|
|
Drive axle speed
|
Ratio Unitary 8.0:1
|
|
Brake front
|
Hydraulic disc brake
|
|
Brake rear
|
Hydraulic disc brake
|
|
Wheel
|
aluminium wheel
|
|
Tire
|
165 /70 R13
|
|
Steering type
|
electric power steering
|
|
Brake assist
|
●
|
|
Configuration
|
|
Windshield wiper
|
●
|
|
Windshield washer
|
●
|
|
Hood
|
Support pole
|
|
Door Lock
|
electric
|
|
Windows
|
electric
|
|
Display screen
|
●
|
|
USB Port
|
●
|
|
Cigar lighter entry port
|
●
|
|
Combined switches
|
●
|
|
Seats
|
Driver co-dirver seperate adjustable
|
|
Sun visor
|
Driver●/Co-diver -
|
|
Roof decoration board
|
●
|
|
Roof handle
|
●
|
|
Heater blower
|
●
|
|
AC
|
●
|
|
Back camera
|
●
|
|
Inner mirror
|
- -
|
|
reading light
|
on the sun visor
|
|
Instrument type
|
LCD Digital Instrument
|
|
Headlamp
|
bulb
|
|
Rear lamp
|
bulb
|
|
Safety belt three point
|
Driver●/Co-driver●
|
|
Mudguard
|
●
|
|
Front storage box
|
- -
|
|
Cell phone holder
|
- -
|
|
Front bull bar
|
●
|
|
Tail logo sticker
|
●(English）
|
|
Driver dislocation alarm
|
●
|
|
Steering anti theft device
|
●
|
|
Front turning signal light
|
●
|
|
Front position lamp
|
●
|
|
Side turning signal light
|
●
|
|
Rear fog light
|
●
|
|
Rear plate light
|
●
|
|
Dide retro-reflector
|
●
|
|
Colour
|
Red, white,blue
|
