外形参数 Size
|
|
总长/总宽/总高Length/Width/Height (mm)
|
6480×2150×2910
|
内高Interior height (mm)
|
1860
|
电机驱动系统 Electric motor performance
|
|
驱动电机型号
Model of power-driven motor
|
WTEM60-40-2
|
驱动电机型式Type of power-driven motor
|
永磁同步电机, 冷却方式:水冷
Permanent magnet synchronous motor, Water cooling
|
额定功率/转速
Rated. power/rotating speed (KW/r/min)
|
60/2550
|
峰值功率/转速
Peak power/rotating speed (KW/r/min)
|
120/7000
|
额定扭矩/转速
Rated. torque/rotating speed (N.m/r/min)
|
225/2550
|
峰值扭矩/转速
Peak torque/rotating speed (N.m/r/min)
|
450/7000
|
燃料种类
Fuel type
|
纯电动 Electric
|
动力电池种类Power battery type
|
磷酸铁锂电池iron phosphate lithium battery
|
电池容量 Battery capacity(kwh)
|
100
|
电池组电压 Voltage(V):
|
540
|
性能参数 Performance
|
|
底盘型号 Chassis model
|
――――
|
最高车速 Top speed (km/h)
|
100
|
轴距(mm)
Axle distance (mm)
|
3430
|
前悬/后悬(mm)
Front overhang / Rear overhang (mm)
|
1170/2000
|
接近角/离去角(º)
Angle of approach / departure (º)
|
11/11
|
前轮距/后轮距(mm)front tread/ rear tread
|
1728/1605
|
制动距离(时速30KM满载状态下)Brake distance (v=30km/h fully loaded)
|
<9m
|
最大爬坡度%
Max. Gradeability
|
27
|
电耗量(kwh/100km) fuel consumption
|
≤50
|
续驶里程Driving range
|
150-200km
|
总质量/整备质量Gross weight/Curb weight(kg)
|
7500/5600
|
基本配置 Basic Specification
|
|
离合器 Clutch
|
----
|
变速器 Transmission
|
四档电控自动变速箱
Four forward gears, electric control, automatic gearbox
|
后桥 Rear axle
|
单级减速,整体式桥壳,速比:
Integral axle housing, single reduction final drive, speed ratio:
|
前桥 Front axle
|
拳端式工字梁结构
Ends fist,Ⅰsection
|
悬架系统 Suspension system
|
钢板弹簧 Leaf spring
|
转向系统 Steering system
|
整体式动力转向、左置Integral power steering, LHD
|
制动系统 Braking system
|
双管路气制动、干燥器 储能弹簧气室、WABCO ABS带刹车间隙自动调整臂,前盘/后鼓制动器
Dual circuit air brake,drier,energy storage spring chamber, WABCO ABS+ automatic backlash adjustment arm,front disc/ rear drum brake
|
轮胎Tire
|
215/75R17.5,有备胎 with spare tire
|
|
|
